Model No. :ECT-SET100

    Max. working thickness 100mm
    Working length 100mm and over
    Feed Chaintrack
    Motor horse power 3(5)hp
    Feed speed 5-25m/min
    Distance between dogs 400(300/200)mm or without dogs
    Moulding Unit 1 (equipped with jumping function)
    Motor horse power 7.5(10)hp
    Spindle speed 4500-8000(10000)rpm
    Spindle diameter 40mm
    Cutter diameter 190-250mm
    Moulding Unit 2
    Motor horse power 10hp
    Spindle speed 4500-6000(10000)rpm
    Spindle diameter 40mm
    Cutter diameter 190-250mm
    Profile Sanding Unit
       Motor horse power 3hp x 3pcs
       Spindle speed 0-1800rpm
    N.W. 4250kg
    G.W. 4600kg
    Machine size 4110x1620x1900mm
    Packing size 4230x1600x2120mm
